Product Overview
The H-CD022 Architectural Low-Voltage Magnetic LED Pendant Light brings elegant cylindrical aesthetics and focused downward spot illumination to modern interiors. Designed to snap effortlessly into DC 24V or DC 48V magnetic track systems, this 9W suspended luminaire combines decorative sophistication with low-voltage functionality.
Crafted from high-grade die-cast aluminum, the H-CD022 features a luxurious dual-tone finish in Sand Black and Painting Gold. Measuring Φ55mm in diameter with a 200mm cylinder body, it incorporates high-CRI LEDs (CRI ≥ 90) and precision lenses (15°, 24°, 36°). It is the perfect lighting choice for kitchen islands, dining spaces, executive office desks, and boutique retail counters.
Key Features & Technical Advantages
-
Tool-Free Magnetic Suspension Integration Engineered for DC24V/48V magnetic track channels, allowing touch-safe installation and easy position adjustments along the rail without tools.
-
Dual-Tone Architectural Finish Combines a durable Sand Black exterior body with an accent Painting Gold baffle, creating a high-end luxury aesthetic for modern spaces.
-
Focused Optical Control (15° / 24° / 36°)
-
15° Narrow Beam: High-intensity spotlight for tight tabletop accenting.
-
24° Medium Beam: Ideal for kitchen islands, bar counters, and dining tables.
-
36° Wide Beam: Broad flood illumination for general surface illumination.
-
Excellent Color Fidelity (CRI ≥ 90) With CRI ≥ 90, food presentation, countertop surfaces, and interior decor retain their natural vibrancy across 3000K, 3500K, and 4000K color temperature options.
-
Durable Aluminum Construction Constructed from die-cast aluminum for optimal heat management and extended chip lifespan.
Product Specifications
-
Model: H-CD022
-
System Power: 9W
-
Operating Voltage: Safe Low Voltage DC 24V / DC 48V
-
Luminous Efficacy: 75 lm/W
-
Color Temperature (CCT): 3000K (Warm White) / 3500K (Neutral White) / 4000K (Cool White)
-
Color Rendering Index (CRI): ≥ 90
-
Beam Angles: 15° / 24° / 36°
-
Downlight Type: Fixed Downward Light
-
Body Material: Aluminium
-
Finish: Sand Black + Painting Gold (砂黑+喷油金)
-
Installation Type: Low-Voltage Magnetic Track Mounted / Pendant Suspended
-
Protection Rating: IP20 (Indoor Use)
-
Certifications: CE, RoHS, CCC
Dimensions & Size Options
Frequently Asked Questions (FAQ)
Q1: What magnetic track systems are compatible with the H-CD022 pendant light? A: The H-CD022 is designed for low-voltage magnetic track systems operating at DC24V or DC48V.
Q2: Can the hanging cable height be adjusted during installation?
A: Yes, the suspension cable can be adjusted during installation to achieve the ideal height above kitchen islands or dining tables.
Q3: Where is the H-CD022 magnetic pendant best utilized? A: It is ideal for modern residential kitchen islands, dining areas, bedside hanging lights, coffee shops, and boutique reception desks requiring low-voltage track flexibility and luxury design.
