H-CS8S Ultra-Slim LED Track Spotlight 10W 15W | Modern Swivel Accent Light

Product Overview

The H-CS8S Ultra-Slim LED Track Spotlight Series offers streamlined aesthetics and precision directional illumination for luxury residential spaces, art galleries, and modern commercial interiors. Engineered with an ultra-compact 20mm track box height, this modern luminaire minimizes ceiling clutter while providing crisp, high-CRI light.

Crafted from premium aluminum with a Sand Black finish, the H-CS8S incorporates high-performance optics (15°, 24°, 36°) and a CRI ≥ 90 rating. Offered in 10W and 15W models, it provides controlled directional lighting for wall artwork, display shelves, and architectural accenting.

Key Features & Technical Advantages

1. Ultra-Slim Profile Design Features a compact 20mm track adapter height and Φ55mm head diameter, maintaining an unobtrusive profile on track rails.

2. Flexible Power Tiers

• H-CS8S-10: 10W | Cylinder Length 82mm

• H-CS8S-15: 15W | Cylinder Length 111mm

3. Precision Optics (15° / 24° / 36°)

• 15° Narrow Spot: High-intensity beam for highlighting specific display objects.

• 24° Medium Accent: Balanced beam for artwork and display shelving.

• 36° Wide Flood: Smooth area coverage for general wall accenting.

4. Excellent Color Fidelity (CRI ≥ 90) With CRI ≥ 90, interior decor, wood finishes, and display merchandise preserve their natural visual richness under 3000K, 3500K, or 4000K CCT options.

5. Premium Aluminium Housing Built from extruded aluminum for effective thermal dissipation and long-term durability.

Product Specifications

• Model Series: H-CS8S Series (H-CS8S-10 / H-CS8S-15)

• System Power Options:

  • H-CS8S-10: 10W

  • H-CS8S-15: 15W

• Luminous Efficacy: 70 lm/W

• Color Temperature (CCT): 3000K / 3500K / 4000K

• Color Rendering Index (CRI): ≥ 90

• Optical Beam Angles: 15° / 24° / 36°

• Body Material: Aluminium

• Available Finish: Sand Black (砂黑)

• Installation Type: Track Mounted

• Protection Rating: IP20 (Indoor Use)

• Certifications: CE, RoHS, CCC

Dimensions & Size Options

• H-CS8S-10 (10W): Head Diameter Φ55mm | Cylinder Length 82mm | Track Base Length 184mm

• H-CS8S-15 (15W): Head Diameter Φ55mm | Cylinder Length 111mm | Track Base Length 184mm

Frequently Asked Questions (FAQ)

Q1: What makes the H-CS8S track spotlight unique? A: The H-CS8S features an ultra-slim track adapter base (only 20mm thick), offering a much sleeker profile than traditional track spotlights.

Q2: How do I choose between the 10W and 15W versions?

A:

• 10W (H-CS8S-10): Ideal for residential living rooms, bedrooms, and low ceilings (2.4m - 2.8m).

• 15W (H-CS8S-15): Recommended for galleries, boutique displays, and medium ceilings (2.8m - 3.2m).
