Architectural Dual-Tone Aesthetics Combines a Matte White outer border with a deep Sand Black internal bezel
Dual-Axis $355^\circ$ Swivel & Tilt Aiming Offers full $355^\circ$ horizontal rotation and vertical tilt mechanism
Modular Cutout & Power Configurations
H-LA098RS: 5W / 7W / 9W | Frame $\Phi62\text{mm}$ | Height $60\text{mm}$ | Ceiling Cutout: $\Phi55\text{mm}$
H-LA098RM: 9W / 12W / 15W | Frame $\Phi85\text{mm}$ | Height $81\text{mm}$ | Ceiling Cutout: $\Phi75\text{mm}$
Precision Beam Selection ($15^\circ$ / $24^\circ$ / $36^\circ$ / $50^\circ$)
$15^\circ$ Narrow Spot: Focused beam for high-intensity spot lighting onto sculptures or small artwork
$24^\circ / 36^\circ$ Medium Accent: Balanced coverage for feature walls and display shelving
$50^\circ$ Wide Flood: Broad coverage for general directional downlighting
High Color Accuracy (CRI $\ge 90$) With CRI $\ge 90$
Model Series: H-LA098R Series (H-LA098RS / H-LA098RM)
Power Options:
H-LA098RS: 5W / 7W / 9W
H-LA098RM: 9W / 12W / 15W
Luminous Efficacy: $50\text{ lm/W}$
Color Temperature (CCT): $3000\text{K}$ (Warm White) / $4000\text{K}$ (Neutral White) / $5000\text{K}$ (Cool Daylight)
Color Rendering Index (CRI): $\ge 90$
Optical Beam Angles: $15^\circ / 24^\circ / 36^\circ / 50^\circ$
Adjustable Movement: Vertical Tilt Articulation | $355^\circ$ Horizontal Swivel
Body Material: Aluminium
Available Finish: Matte White + Sand Black Dual-Tone (哑白+砂黑)
Installation Type: Recessed Ceiling Mounted
Protection Rating: IP20 (Indoor Use)
Certifications: CE, RoHS, CCC
