Product Overview
The H-LB023-1 Square Recessed LED Downlight brings clean geometric styling and precise optical performance to modern interior spaces. Designed with a compact 75x75mm square profile, this 9W architectural fixture embeds smoothly into ceiling drywall to deliver glare-controlled accent and task illumination.
Constructed from premium die-cast aluminum in a refined Sand White finish, the H-LB023-1 offers high color rendering performance (CRI ≥ 90) and multiple CCT options (3000K, 4000K, 5000K). Equipped with precision beam lenses (15°, 24°, 36°), it provides tailored focal lighting for artwork, wall displays, kitchen counters, and hotel corridors.
Key Features & Technical Advantages
-
Minimalist Square Architectural Design Features a sleek 75 x 75mm Sand White square frame that provides a clean, modern aesthetic for contemporary ceiling layouts.
-
Precision Beam Distribution (15° / 24° / 36°)
-
15° Narrow Spot: High-intensity beam for tight accent lighting on artwork or displays.
-
24° Medium Beam: Balanced coverage for task areas and feature walls.
-
36° Wide Flood: Smooth, uniform light distribution for ambient spatial downlighting.
-
True-Color Fidelity (CRI ≥ 90) With a high Color Rendering Index of ≥90, indoor materials, wood grains, and decor preserve their natural visual depth across 3000K, 4000K, or 5000K options.
-
Efficient 85 lm/W Performance Provides bright, energy-saving light output (85 lm/W) while maintaining optimal thermal management through its aluminum housing.
-
Durable Aluminum Construction Machined from high-grade aluminum to ensure efficient heat dissipation and extended LED chip durability.
Product Specifications
-
Model: H-LB023-1
-
System Power: 9W
-
Luminous Efficacy: 85 lm/W
-
Color Temperature (CCT): 3000K (Warm White) / 4000K (Neutral White) / 5000K (Cool Daylight)
-
Color Rendering Index (CRI): ≥ 90
-
Optical Beam Angles: 15° / 24° / 36°
-
Body Material: Aluminium
-
Available Finish: Sand White (砂白)
-
Faceplate Dimensions: 75 x 75mm
-
Installation Type: Recessed Ceiling Mounted
-
Protection Rating: IP20 (Indoor Use)
-
Certifications: CE, RoHS, CCC
Dimensions & Cutout Data
-
Panel Size: 75 x 75mm
-
System Power: 9W
Frequently Asked Questions (FAQ)
Q1: What is the main application for the H-LB023-1 square downlight? A: The H-LB023-1 is ideal for modern residential living rooms, hallways, hotel rooms, retail boutiques, and display niches requiring a clean square aesthetic with precise spot lighting.
Q2: Which beam angle should I choose?
A:
-
15°: Best for concentrated accent lighting on sculptures, small artwork, or focal items.
-
24°: Ideal for general accent lighting, wall washing, and kitchen counters.
-
36°: Best for general area lighting and wider spatial coverage.
Q3: Is this light suitable for residential and commercial projects? A: Yes, with CRI ≥ 90, 85lm/W efficacy, and high-quality aluminum construction, it meets strict architectural lighting standards for both upscale homes and commercial venues.
