Three Modular Power Options Select from H-LD072S (15W/Φ55mm), H-LD072M (25W/Φ65mm), and H-LD072L (35W/Φ75mm)
Dual-Axis 355° Swivel & 90° Tilt Multi-directional positioning capabilities
Versatile Optical Beam Angles (15° / 24° / 36°)
15° Narrow Beam: Focuses light for distant accenting on sculptures, artwork, and key displays
24° Medium Beam: Ideal for balanced retail display lighting and wall features
36° Wide Beam: Delivers broad, uniform flood coverage for general commercial areas
Excellent Color Fidelity (CRI ≥ 90) With a high Color Rendering Index of ≥90
Durable Aluminium Housing Built from extruded die-cast aluminum for optimal thermal management and extended chip longevity
Model Series: H-LD072 Series (H-LD072S / H-LD072M / H-LD072L)
System Power & Efficacy:
H-LD072S: 15W | 85 lm/W
H-LD072M: 25W | 85 lm/W
H-LD072L: 35W | 85 lm/W
Color Rendering Index (CRI): ≥ 90
Color Temperature (CCT): 3000K (Warm White) / 4000K (Neutral White) / 5000K (Cool Daylight)
Beam Angles: 15° / 24° / 36°
Adjustable Angles: 355° Horizontal Swivel | 90° Vertical Tilt
Body Material: Aluminium
Available Finishes: Sand White (砂白) / Sand Black (砂黑)
Installation Type: Track Mounted
Protection Rating: IP20 (Indoor Use)
Certifications: CE, RoHS, CCC
H-LD072S (15W): Cylinder Diameter Φ55mm | Cylinder Length 125mm | Base Adapter 149mm
H-LD072M (25W): Cylinder Diameter Φ65mm | Cylinder Length 135mm | Base Adapter 149mm
H-LD072L (35W): Cylinder Diameter Φ75mm | Cylinder Length 145mm | Base Adapter 149mm
15W (H-LD072S): Ideal for residential interiors and low ceilings (2.4m - 2.8m)
25W (H-LD072M): Recommended for retail stores and medium ceilings (2.8m - 3.5m)
35W (H-LD072L): Best for galleries, high-ceiling retail, and spaces above 3.5m
