Product Overview
The H-LD075 Commercial LED Linear Track Light Series brings versatile, high-efficiency, and evenly distributed flood illumination to modern architectural and commercial spaces. Designed with a slim profile and dual adjustable end-mounts, this fixture offers 90° vertical tilting flexibility, allowing you to switch seamlessly between ambient downlighting and wall-washing application.
Crafted from high-grade extruded aluminum with durable sand white and sand black finishes, the H-LD075 series ensures efficient thermal dissipation, long operating life, and a minimal visual impact on track systems.
Key Features & Technical Advantages
-
High Efficiency & Energy Saving (150 lm/W) Built with high-performance LED chips, generating up to 150 lm/W to deliver high lux levels while lowering overall power consumption.
-
100° Wide Flood Optics Features a frosted diffuser panel combined with a 100° wide beam angle, reducing dark areas and delivering soft, glare-free ambient illumination.
-
True-to-Life Color Rendering (CRI ≥ 90) High Color Rendering Index (CRI ≥90) accurately displays the natural colors of merchandise, artwork, and interior finishes.
-
90° Vertical Tilt Adjustability Equipped with dual precision side dials supporting 90° vertical rotation, giving you complete freedom to direct light onto walls, shelving, or task zones.
-
Sleek Architectural Track Integration Low-profile linear body with integrated track adapters ensures clean alignment with standard commercial track systems.
Product Specifications
-
Model Series: H-LD075 (H-LD075-06 / H-LD075-09 / H-LD075-12)
-
Power Options: 25W (06) / 35W (09) / 45W (12)
-
Luminous Efficacy: 150 lm/W
-
Color Rendering Index (CRI): ≥ 90
-
Color Temperature (CCT): 3000K (Warm White) / 4000K (Neutral White) / 5000K (Cool White)
-
Beam Angle: 100° Wide Flood
-
Housing Material: High-Grade Aluminum (铝)
-
Finish Options: Sand White (砂白), Sand Black (砂黑)
-
Tilt Adjustability: 90° Vertically Adjustable
-
IP Rating: IP20 (Indoor Use)
-
Certifications: CE, RoHS, CCC
Dimensions & Models Quick Selection
-
H-LD075-06 (25W): Body Length: 591mm | Total Width with Connectors: 681mm | Profile: 80mm x 33mm
-
H-LD075-09 (35W): Body Length: 886mm | Total Width with Connectors: 978mm | Profile: 80mm x 33mm
-
H-LD075-12 (45W): Body Length: 1181mm | Total Width with Connectors: 1271mm | Profile: 80mm x 33mm
Frequently Asked Questions (FAQ)
Q1: What is the main difference between linear track lights and spotlight track lights? A: Linear track lights like the H-LD075 provide broad, diffuse 100° floodlighting for overall ambient illumination or wall washing, whereas spotlights feature narrow beams (24°/36°) designed for focused accent lighting on specific items.
Q2: Where is the H-LD075 linear track light best applied? A: It is ideal for open-plan offices, supermarket aisles, retail clothing store ambient zones, art galleries, corridors, and conference rooms where smooth, shadow-free lighting is needed.
Q3: Can the angle of the linear light be adjusted after mounting? A: Yes, the end mounting brackets allow up to 90° vertical tilting, enabling you to adjust the light from straight-down ambient lighting to angled wall-washing illumination.
