Huiheng Lighting Square High-Power Adjustable Recessed LED Downlight — H-LC109-1 Series

The H-LC109-1 Series Square High-Power Adjustable Recessed LED Downlight by Huiheng Lighting delivers a bold, geometric architectural aesthetic combined with heavy-duty commercial lighting performance. Designed with a modern square trim, high luminous efficacy up to 85 lm/W, and power options up to 35W, this spotlight features an internal tiltable gimbal light engine. It is the premier choice for architects and designers seeking linear symmetry, precise accent lighting, and high-lumen output for high-ceiling villas, luxury hotels, and commercial spaces.

Key Features & Performance Highlights

• Modern Square Architectural Design: Features a stylish square recessed trim that aligns with linear ceiling grids, adding clean geometric symmetry to modern interiors.

• High Output & High Luminous Efficacy (85 lm/W): Available in 15W, 25W, and 35W options delivering strong brightness with an efficient 85 lm/W output—ideal for medium-to-high ceiling environments.

• Precision Adjustable Swivel & Tilt Light Engine: Incorporates a 355° horizontal rotation and flexible tilting head within the square frame, allowing light to be pointed accurately onto feature walls, artwork, or displays.

• Exceptional Color Rendering Index (CRI ≥ 90): Equipped with high-quality LED COB chips (CRI ≥ 90) to accurately render natural colors and surface textures of interior materials and merchandise.

• Multiple Optical Beam Angle Options: Select from 15° (narrow spot), 24° (medium spot), 36° (wide spot), and 50° (flood light) to customize light layering for different ceiling heights.

• Versatile CCT Options: Offered in 3000K Warm White (cozy & elegant), 4000K Natural White (clean & modern), and 5000K Cool Daylight (bright & crisp).

• Heavy-Duty Heat-Sink & Premium Finish: Built from high-grade die-cast aluminium with an aggressive radiator housing in an elegant Sand White + Sand Black dual-tone finish.

• Certified Quality & Safety: Fully compliant with CE, RoHS, and CCC standards, with an IP20 protection rating for indoor applications.

Product Specifications Matrix

• Brand: Huiheng Lighting

• Model Options: H-LC109M-1 (15W) / H-LC109L-1 (25W) / H-LC109I-1 (35W)

• Shape / Trim: Square Recessed Frame

• Power Output:

  • H-LC109M-1: 15W

  • H-LC109L-1: 25W

  • H-LC109I-1: 35W

• Square Ceiling Cutout Size:

  • H-LC109M-1: 80 × 80 mm

  • H-LC109L-1: 100 × 100 mm

  • H-LC109I-1: 135 × 135 mm

• Overall Dimensions:

  • H-LC109M-1: 95 × 95 mm × Height 72 mm

  • H-LC109L-1: 118 × 118 mm × Height 87 mm

  • H-LC109I-1: 155 × 155 mm × Height 109 mm

• Luminous Efficacy: 85 lm/W

• Color Rendering Index: CRI ≥ 90

• Color Temperature (CCT): 3000K / 4000K / 5000K

• Beam Angle Options: 15° / 24° / 36° / 50°

• Adjustability Type: Adjustable / Tiltable Gimbal + 355° Horizontal Swivel

• Housing Material & Finish: High-Grade Aluminium (Sand White + Sand Black)

• IP Protection Rating: IP20 (Indoor Ceiling Recessed)
